FlexyRap
Cobalt Chromium Rapamycin Eluting Coronary Stent System
The FlexyRap® Cobalt Chromium Rapamycin Eluting Coronary Stent System offers an U.S. Patented stent design, engineered for excellent deliverability, radial strength and vessel scaffolding.
The FlexyRap® Cobalt Chromium Rapamycin Eluting Coronary Stent System is proven to be safe and effective in a prospective, multi-center, observational study in a real-world, all-comers CAD patients including those with high-risk and very complex lesions, indicating low rates of MACE over 2-year follow-up period*
Specifications
CoCr L605
60μm
0.014"
2.8%
MR conditional
0.95mm
<0.5mm
145cm
1%
5F
DOWNLOAD e-BROCHURE
We strive to provide you with the detailed information of your desired choice of product.
The product story folded in the brochure to unfold the same download e-Brochure and know more about the key features, benefits, technical specifications and others.
Inquiry Now Download e-BrochurePt-Ir Radioopaque markers for better Visibility.
Kink Resistance Catheter Shaft for better Pushability.
Kink Resistance Catheter Shaft for better Pushability.
Tapered 4-5mm tip for distal stability and guidewire support.
More awesome features
See some of our awesome key features
excellent biocompatibility Sustained Rapamycin (Sirolimus) release
over 28 days for therapeutic efficacy. Semi Open (Hybrid) U.S.
Patented Stent Design. Drug : Rapamycin (Sirolimus)
Dose: 1μg/mm2 Superior Stent mechanics through
strong cobalt chromium alloy. Better fatigue and corrosion
resistance performance. Coating thickness less than 6μ Growth of 8% from nominal pressure
to RBP allowing complete deployment
and good wall apposition. Ultrasmooth Electropolished finishing.
Technical Data
Catalog No.
| Length/Dia | 2.25mm | 2.50mm | 2.75mm | 3.00mm | 3.50mm | 4.00mm |
|---|---|---|---|---|---|---|
| 07mm | FR 0722 | FR 0725 | FR 0727 | FR 0730 | FR 0735 | FR 0740 |
| 10mm | FR 1022 | FR 1025 | FR 1027 | FR 1030 | FR 1035 | FR 1040 |
| 13mm | FR 1322 | FR 1325 | FR 1327 | FR 1330 | FR 1335 | FR 1340 |
| 15mm | FR 1522 | FR 1525 | FR 1527 | FR 1530 | FR 1535 | FR 1540 |
| 17mm | FR 1722 | FR 1725 | FR 1727 | FR 1730 | FR 1735 | FR 1740 |
| 20mm | FR 2022 | FR 2025 | FR 2027 | FR 2030 | FR 2035 | FR 2040 |
| 24mm | FR 2422 | FR 2425 | FR 2427 | FR 2430 | FR 2435 | FR 2440 |
| 28mm | FR 2822 | FR 2825 | FR 2827 | FR 2830 | FR 2835 | FR 2840 |
| 33mm | FR 3322 | FR 3325 | FR 3327 | FR 3330 | FR 3335 | FR 3340 |
| 38mm | FR 3822 | FR 3825 | FR 3827 | FR 3830 | FR 3835 | FR 3840 |
| 42mm | FR 4222 | FR 4225 | FR 4227 | FR 4230 | FR 4235 | FR 4240 |
| 45mm | FR 4522 | FR 4525 | FR 4527 | FR 4530 | FR 4535 | FR 4540 |
Compliance Chart
| Pressure(bar) | Diameters | ||||||
| 2.25mm | 2.50mm | 2.75mm | 3.00mm | 3.50mm | 4.00mm | 4.50mm | |
|---|---|---|---|---|---|---|---|
| 4 | 1.98 | 2.25 | 2.48 | 2.74 | 3.25 | 3.72 | 4.37 |
| 6 | 2.13 | 2.39 | 2.62 | 2.88 | 3.35 | 3.85 | 4.42 |
| 8 | 2.25 | 2.50 | 2.75 | 3.00 | 3.50 | 4.00 | 4.50 |
| 9 | 2.28 | 2.54 | 2.78 | 3.03 | 3.54 | 4.07 | 4.55 |
| 10 | 2.31 | 2.57 | 2.82 | 3.10 | 3.57 | 4.14 | 4.63 |
| 11 | 2.33 | 2.60 | 2.86 | 3.13 | 3.60 | 4.19 | 4.69 |
| 12 | 2.35 | 2.62 | 2.89 | 3.17 | 3.63 | 4.25 | 4.75 |
| 13 | 2.37 | 2.64 | 2.91 | 3.19 | 3.66 | 4.28 | 4.81 |
| 14 | 2.39 | 2.66 | 2.93 | 3.21 | 3.70 | 4.32 | 4.86 |
| 15 | 2.41 | 2.68 | 2.95 | 3.23 | 3.74 | 4.35 | 4.91 |
| 16 | 2.43 | 2.70 | 2.97 | 3.25 | 3.78 | 4.38 | 4.96 |
| 17 | 2.45 | 2.73 | 3.00 | 3.28 | 3.81 | 4.40 | 5.01 |
| 18 | 2.48 | 2.76 | 3.03 | 3.31 | 3.84 | 4.42 | 5.06 |
| Nominal Pressure | Rated Burst Pressure |
Clinical Outcome
| Outcomes | 6 Months | 9 Months | 12 Months | 24 Months |
|---|---|---|---|---|
| MACE, n (%) | 0 (0.0%) | 2 (2.1%) | 6 (6.2%) | 6 (6.2%) |
| All cause of death, n (%) | 0 (0.0%) | 0 (0.0%) | 0 (0.0%) | 0 (0.0%) |
| Cardiac, n (%) | 0 (0.0%) | 0 (0.0%) | 0 (0.0%) | 0 (0.0%) |
| Non-Cardiac, n (%) | 0 (0.0%) | 0 (0.0%) | 0 (0.0%) | 0 (0.0%) |
| MI, n (%) | 0 (0.0%) | 0 (0.0%) | 1 (1.0%) | 1 (1.0%) |
| Indicated TLR, n (%) | 1 (1.0%) | 2 (2.1%) | 5 (5.2%) | 5 (5.2%) |
